SPÉCIFICATIONS
CADRE
META POWER SX BOSCH, 165 mm travel
29″-27.5″, Alloy 6066, triple butted tubes, T4, T6.
MOTEUR
BOSCH Performance Line CX
Max. torque: 85N.m, 250W
BATTERIE
BOSCH PowerTube 625, 625Wh
BOSCH 4A Charger, Compact size & lightweight
Compatible w/Bosch PowerMore 250 for extra range
AFFICHAGE
BOSCH System Controller
BOSCH Mini Remote currently not available in the USA
AMORTISSEUR
FOX Float X Performance
230 x 65 mm, LSC, rebound, 2-position open / firm lever, 0.6 spacer
FOURCHE
FOX 38 Performance E-Bike, 170 mm travel
29″, Fit Grip damper, 3 positions compression, rebound, Boost (15 x 110 mm), 44 mm offset, 3 spacers
JEU DE DIRECTION
ACROS ZS56 / ZS66
Alloy cups, sealed bearings
POTENCE
RIDE ALPHA 40 EXTERNAL
40 mm extension, 31,8 mm
CINTRE
RIDE ALPHA R20 POWER on S – RIDE ALPHA R27 POWER on M / L / XL
Internal Di2 cable routing – 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
POIGNÉES
ODI Longneck
Soft pro compound, single clamp, black
FREINS
SHIMANO SLX, 4 pistons, resin pads, I-Spec EV compatible
Rotors: SHIMANO SM-RT66 220 mm, 6-bolt
SHIFTERS
SHIMANO SLX
12s, RapidFire Plus
GUIDE CHAINE
RIDE ALPHA Upper Guide
32-34t
DÉRAILLEUR
SHIMANO SLX
12s
BOITIER DE PÉDALIER
BOSCH
PÉDALIER
E13 E*Spec Plus BOSCH CX, 160 mm crank arms
Chainring: E13 E*Spec Plus BOSCH CX, 34t, direct mount
CHAINE
SHIMANO SLX
12s
CASSETTE
SHIMANO SLX
12s, 10-51t
JANTES
Rear: DT SWISS H1900 Spline – Front: DT SWISS H1900 Spline
Rear: 27.5 », 28h, 30 mm inner width – Front: 29 », 28h, 30 mm inner width
MOYEUX
Rear: DT SWISS 370 – Front: DT SWISS 370
Rear: 28h, 12 x 148 mm, sealed bearings, 18t, e-bike specific – Front: 28h, 15 x 110 mm, sealed bearings
RAYONS
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
PNEUS
Rear: MAXXIS DHR II – Front: MAXXIS Assegai
Rear: 27.5″ x 2.4″ WT, 3C MaxxTerra, Double Down, Tubeless Ready – Front: 29″ x 2.5″ WT, 3C MaxxGrip, Exo+, Tubeless Ready
TIGE DE SELLE
KS Rage I
31.6 mm, travel: 125 mm on S, 170 mm on M/L, 190 mm on XL, SouthPaw alloy remote
SELLE
FIZIK Terra Aidon X5
145 mm width, S-Alloy Mobius rails
POIDS
25 kg / 55.11 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PÉDALES INCLUSES
Yes
COULEUR
Pure White
Shiny Finish
ACCESSOIRES
RIDE ALPHA CNC pedals, motor protector, chainstay protector, seatstay protector, user manual
*Actual product may differ from pictures.
*Please note that bike specs are subject to change without prior notice.
