SPÉCIFICATIONS
CADRE
CLASH, 170 mm travel
27.5 », Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
AMORTISSEUR
ROCKSHOX Deluxe Select +
230 x 65 mm, RT damper, DebonAir Linear, rebound, 2 pos comp, (open/firm), 1 Token neg. 4 Token pos.
FOURCHE
ROCKSHOX Domain R, 180 mm travel
27.5″, DebonAir, external rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token
JEU DE DIRECTION
ACROS ZS44/ZS56
Alloy cups, sealed bearings
POTENCE
RIDE ALPHA Freeride 40
40 mm extension, 31.8 mm
CINTRE
RIDE ALPHA R20 760 on S – RIDE ALPHA R27 780 on M / L – RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
POIGNÉES
RIDE ALPHA DH
Ultra-soft compound, single clamp, black
FREINS
SRAM Guide T, 4 pistons, MatchMaker compatible
Rotors: SRAM G2 CleanSweep 200 mm, 6-bolt
SHIFTERS
SRAM SX Eagle
12s
GUIDE CHAINE
–
DÉRAILLEUR
SRAM SX Eagle
12s
BOITIER DE PÉDALIER
SRAM DUB
Pressfit
PÉDALIER
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM X1 1000 Eagle, 34t, Narrow-Wide
CHAINE
SRAM NX Eagle
12s
CASSETTE
SRAM PG-1210
12s, 11-50t
JANTES
E13 LG1 DH Base
27.5 », 32h, 30 mm inner width
MOYEUX
Rear: FORMULA DCL-348A – Front: FORMULA DC-711
Rear: 32h, 12 x 148 mm, sealed bearings, Shimano Hyperglide – Front: 32h, 15 x 110 mm, sealed bearings
RAYONS
SAPIM Race
J-Bend, 2.0-1.8-2.0 mm, double butted, stainless, with Nylok, black
PNEUS
Rear: MAXXIS DHR II – Front: MAXXIS Assegai
Rear: 27.5″ x 2.4″, WT, 3C MaxxTerra, EXO+, Tubeless Ready – Front: 27.5″ x 2.5″, WT, 3C MaxxGrip, EXO+, Tubeless Ready
TIGE DE SELLE
RIDE ALPHA
34.9 mm, 400 mm on S/M, 450 mm on L/X
SELLE
SDG Bel Air V3
140 mm width, Steel Rails
POIDS
15,5 kg / 34.17 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PÉDALES INCLUSES
No
COULEUR
Heritage Green
Shiny Finish
ACCESSOIRES
Down tube protector, chainstay protector, seatstay protector, shuttle pad
