SPÉCIFICATIONS
CADRE
2022 Meta HT AM – 29 »/27 » on S / M & 29 »/29 » on L / XL
Alloy 6061, triple butted tubes, T4, T6.
FOURCHE
ROCKSHOX 35 Gold RL, 150 mm travel
29″, Motion Control Damper, DebonAir, rebound, LSC to lock, Boost (15 x 110 mm), 44 mm offset, 0 Token
JEU DE DIRECTION
ACROS ZS44 / ZS56
Alloy cups, sealed bearings
POTENCE
RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm
CINTRE
RIDE ALPHA R20 on S – RIDE ALPHA R27 on M / L / XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
POIGNÉES
ODI Elite Motion
Soft pro compound, single clamp, black
FREINS
SRAM Level, 2 pistons, Hydraulic disc brake
Rotors: SRAM G2 CleanSweep 200 / 180 mm, 6-bolt
SHIFTERS
SRAM SX Eagle
12s
DÉRAILLEUR
SRAM SX Eagle
12s
BOITIER DE PÉDALIER
SRAM BSA
Threaded
PÉDALIER
SRAM X1 1000 Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide
CHAINE
SRAM NX Eagle
12s
CASSETTE
SRAM PG-1210
12s, 11-50t
JANTES
E13 LG1 EN Base
Rear: 27.5 », 32h, 30 mm inner width on S / M – 29 », 32h, 30 mm inner width on L / XL – Front: 29 », 32h, 30 mm inner width on S / M / L / XL
MOYEUX
Rear: FORMULA DC-348A – Front: FORMULA DC-711
Rear: 32h, sealed bearings, 12 x 148 mm, SHIMANO Hyperglide – Front: 32h, sealed bearings, 15 x 110 mm
RAYONS
SAPIM Leader
J-Bend 2.0 mm, stainless, with Nylok, black
PNEUS
Rear: MAXXIS Dissector – Front: MAXXIS Dissector
Rear: 27.5 » x 2.6’’, dual compound, EXO, Tubeless Ready on S / M – 29 » x 2.6 », dual compound, EXO, Tubeless Ready, on L / XL – Front: 29″ x 2.6″, dual compound, EXO, Tubeless Ready on S / M / L / XL
TIGE DE SELLE
RIDE ALPHA
31,6 mm, 400 mm on S/M, 450 mm on L/X
SELLE
SDG Bel Air V3
140 mm width, Steel rails
POIDS
14,2 kg / 31.30 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
PÉDALES INCLUSES
No
COULEUR
Dirt
Matte Finish
ACCESSOIRES
Chainstay protector, seatstay protector
